MC-RF3.81HXXP-D-0001
MC-RF3.81HXXP-D-0001
3.81mm，160V，8A
CE
| 产品型号 SUPU ID |
MC-DPAN3.81VXX-D-BK-2600 | ||
| 产品间距 Pitch |
3.81mm | ||
| 产品层数 Number of levels |
2 | ||
| 产品位数 Number of connections |
4P-48P | ||
| 接线方式 Connection method |
- | ||
| 防护等级 Protection Level |
IP20 | ||
| 工作温度 Work temperature |
-40~+105℃ | ||
| 额定电流 Rated Current |
8A | ||
| 额定电压 Rated Voltage |
160V | ||
| 过压类别 Overvoltage category |
Ⅲ | Ⅲ | Ⅱ |
| 污染等级 Pollution degree |
3 | 2 | 2 |
| 额定冲击电压 Rated impulse voltage |
2.5KV | 2.5KV | 2.5KV |
| 额定电压 Rated Voltage |
160V | 160V | 250V |
| 硬导线截面积 Conductor cross section solid |
- | ||
| 柔性导线截面积 Conductor cross section flexible |
- | ||
| 柔性导线截面积，带绝缘管套 Conductor cross section flexible,with furrule |
- | ||
| 锁线螺钉规格 Locking screw Specification |
- | ||
| 额定扭矩 Rated Torque |
- | ||
| 固定螺钉规格 Fixed Screw Specification |
- | ||
| 额定扭矩 Rated Torque |
- | ||
| 剥线长度 Stripping length |
- |
| 使用组别 Use group |
B |
C |
D |
| 额定电流 Rated Current |
8A |
- | 8A |
| 额定电压 Rated Voltage |
150V |
- | 150V |
| 额定接线容量 Rated cross section |
- |
| 绝缘材料 Insulation material |
LCP |
| 绝缘材料组别 Insulation material group |
Ⅲa |
| 阻燃等级，符合UL94 Flame retardant grade, UL94 compliance |
V0 |
| 导电体材料 Contact material |
Copper alloy |
| 导电体表面镀层 Surface characteristics |
Sn,Plated |
| 认证图标 Certificate |
 |
||
| UL证书号 UL file No. |
|||
| VDE证书号 VDE No. |
|||
| TUV证书号 TUV No. |
|||
